Name: KQS-WSM Mini Integrated Weather Station with 5-in-1 Sensor IP64 Protection and Low Power Consumption
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: KQS-WSM
Price: 5,000.00 USD
Availability: InStock

Ev > Ürünler > Environmental Monitoring >

KQS-WSM Mini Integrated Weather Station with 5-in-1 Sensor IP64 Protection and Low Power Consumption

Menşe yeri:

Çin

Marka adı:

KunQuan

Sertifika:

Model numarası:

KQS-WSM

Bizimle İletişim

Teklif Et

KQS-WSM Mini Integrated Weather Station with 5-in-1 Sensor IP64 Protection and Low Power Consumption

Ürün Ayrıntıları

Sensör Tipi:

5'i 1 arada Entegre (Rüzgar, Sıcaklık, Nem, Basınç)

Ağırlık:

240 gr

Boyutlar:

Yükseklik ~17 cm, Maksimum Çap. ~10cm

Güç Tüketimi:

< 150 mW Toplam

Koruma Derecesi:

IP64

İletişim:

RS485/RS232/TTL (Modbus-RTU)

Ödeme ve Nakliye Şartları

Min sipariş miktarı

1 adet

Ambalaj bilgileri

Her ünitenin ayrı bir kutusu vardır ve tüm kutular standart paketlerde veya müşteri istekleri halind

Teslim süresi

5-8 iş günü

Ödeme koşulları

L/C,D/A,D/P,T/T,Western Union,MoneyGram

Yetenek temini

Haftada 1000 Adet/Adet pazarlık yapılabilir

İlişkili Ürünler

KQS-ZSYT Fully Automatic Direct-Diffuse Integrated Radiation Monitoring Instrument with High Accuracy Dual Tracking Global Applicability and Multiple Communication Options

En İyi Fiyatı Alın

KQZ-GF Photovoltaic Weather Station with Meteorological-Grade Sensors, Fully Waterproof Design, and Customizable Mounting Pole

En İyi Fiyatı Alın

KQZ-BX Portable Weather Station with Fully Waterproof Design, Built-in Battery, and Foldable/Telescopic Structure

En İyi Fiyatı Alın

KQS-GTM Tubular Multi-layer Soil Moisture Monitoring Instrument with FDR Technology for Multi-layer Monitoring (10/20/30/40 cm) and Solar Power

En İyi Fiyatı Alın

Bizimle İletişim

Şimdi iletişime geçin

Ürün Tanımı

KQS-WSM Mini Integrated Weather Station

KQS-WSM Mini Integrated Weather Station

The KQS-WSM mini integrated weather station is a compact, highly integrated environmental monitoring sensor. Compared with traditional all-in-one environmental sensors, it features a smaller design while maintaining powerful functionality. It can quickly and accurately measure five meteorological parameters: wind speed, wind direction, air temperature, humidity, and atmospheric pressure.

It is widely used for environmental monitoring in agriculture, meteorology, forestry, power systems, chemical plants, ports, railways, and highways.

Technical Parameters

Measurement Item (Optional)	Range	Accuracy	Resolution	Power Consumption
Wind speed	0-45 m/s	Start wind speed ≤ 0.8 m/s, ±(0.5 + 0.02V) m/s	0.1 m/s	40 mW
Wind direction	0-359°	±3°	1°	--
Air temperature	-40-80°C	±0.3°C	0.1°C	1 mW
Air humidity	0-100% RH	±5% RH	0.1% RH	--
Atmospheric pressure	300-1100 hPa	±0.5 hPa (25°C)	0.1 hPa	0.1 mW

Total sensor power consumption: <150 mW

Power supply: DC 5V / DC 9-30V / Others optional

Communication: RS485 (Modbus-RTU) / RS232 (Modbus-RTU) / TTL (Modbus-RTU)

Cable length: Standard 2 m

Weight: 240 g

Operating environment: 0-100% RH, -40°C to +60°C

Protection rating: IP64

Product Features

Integrated design enabling simultaneous monitoring of wind speed, wind direction, temperature, humidity, and atmospheric pressure
Measurement elements can be optionally configured as 2-parameter, 4-parameter, or 5-parameter combinations based on requirements
Compact and lightweight design: height approx. 17 cm, maximum diameter approx. 10 cm, weight under 0.25 kg, easy to install
Advanced filtering algorithm with special compensation for rain and fog conditions, ensuring stable and consistent data output
Each unit is calibrated before leaving the factory using wind tunnel and high/low temperature calibration chambers, ensuring compliance with national standards
Strong environmental adaptability, tested under high/low temperature, waterproof, and salt spray conditions

Dimensions
